thin wall food container mould

Thin wall products are increasingly used in our normal lives. There are many thin wall food container moulds with different shapes and uses on the market. These moulds can be used to produce plastic containers which packaging cheese, ice cream, chocolate, fresh fruit, snacks, etc. Thin wall moulds can save a lot of plastic and reduce costs. Therefore, mould manufacturers try to use thin wall moulding technology in more areas.

Thin wall container mould manufacturers in China

Guoguang Mould, a professional thin wall food container mould maker. The moulds we manufacture are round, square and oval, In addition, we support custom moulds of any shape, specification and capacity. Guoguang has a dust-free injection workshop equipped with robotic parts to improve the production efficiency. Customers can choose to produce thin wall containers in Guoguang, or ask us to provide you with food container moulding solutions. We will match you with the most suitable injection moulding machine to manufacture containers with optimal structures. The thin wall food container mould manufactured by our company can achieve 5s automatic production. Equipped with a robot can produce and run faster, and the robot can help you directly After the stacking is completed, the belt will be directly packaged and shipped. In addition, We can provide IML technology according to customer requirements.

How to order thin-wall food container mould?

• Step 1, you need to choose the appropriate product specifications and shapes: the current market shapes include round and rectangular shapes. The conventional capacities are 500ml, 750ml, and 1000ml. The rounded products are slightly lighter than the square ones. The most important factor for thin wall food container moulds is the thickness. The thinner the product, the better, because it may increase the cost of materials and the production cycle
• Step 2, the selection of the mould material: because the thickness of the thin wall mould is only 0.4-0.8mm, the injection moulding machine adopts a high-speed injection moulding machine, and the mould needs to withstand high pressure, so the thin wall mould needs high-hardness steel to prevent the mould Under the long-term high-speed and high-pressure mould deformation, the product flashes and increases the cost. S420 and S136 steel materials are the most ideal. The hardness of steel materials can reach HRC45-52 after vacuum quenching.
• Step 3, mould design: Guoguang mould has 50 excellent professional design teams, thin-wall mould design needs to consider the following points: product parting surface, product wall thickness design, mould exhaust design, mould waterway design, Mold blowing position and direction design, these problems directly determine the success or failure of a thin wall mould. In a short cycle time, our designers will analyze the product according to customer requirements, and then try to find the best cooling water path for the mould. The cavity of the thin wall food container mould will use a separate mould clamping device, which is conducive to controlling the concentricity of the product and also plays a vital role in the daily maintenance of the mould. Our technical team developed a high-speed injection moulding thin wall container characterized by a 4-cavity mould with a thickness of 0.35mm, 0.5L, and a period of 3.5S.
• Step 4, Mould rough machining, heat treatment, CNC machining, wire cutting.
• Step 5, Assemble, test, ship
